Level Switch
Displacer Level Switch
Works on force Balance principle, Dispacer is suspended by a spring. When liquid level rises and covers the displacer, it becomes lighter and the spring relaxes. This causes a small upward movement of the rod assembly inside the casing which activates the magneticallt operated micro switch.
Specifications
Category
Level Switch
Manufacturer
Flowman Engineers
Certification
ISO 9001:2015
Origin
Gujarat, India
Technical Details
Product Information
Mounting : Min 50 NB to 300 NB
Ideal for Deep tank or Sump for low Alarm.
Pressure: Vacuum to 15 Kg/cm²
Two Displacers available for pump control.
Suitable for high Temperature.
External cage on request.
For High Temperature (Max 350ºC on request)
